BEAMER 3 light
Technical
Fast opening. Opening time is the most important reserve criterion. If a reserve has to be thrown at low altitude – and that is often the case – a single second can make all the difference. The Beamer 3’s special shape and particular folding technique help it open up to 50% faster than normal round canopies; the Beamer 3 is setting EN Test records.
Low sink speed. Assuming a reserve is open with its paraglider in a stable situation the next most important thing is sink speed. Low wing loading and modest forward speed give the Beamer 3 an unrivalled low sink rate. The EN certification authority has confirmed a sink rate of 3.9 m/s at maximum weight of 130 kg (without the paraglider). The additional braking effect of a paraglider reduces this value to less than 3m/s.
Stable flight. When developing a Rogallo our main focus is how it works with the paraglider. After reserve opening the paraglider can stay attached (the usual emergency situation – no quick release/cutaway). Here the Beamer 3 really plays its trump card, and is far superior to the smaller models on the market in this respect. After a fast opening the Beamer 3 quickly takes control. It goes into very slow forward flight and therefore does not encourage the paraglider to disturb it. The Beamer 3 achieves Its stability, among other things, by its low wing loading. This accords with our recommendation: Don’t put your trust in anything under 40 m2.
Braked opening configuration
As a special feature we elected to further develop the braked opening configuration for the Rogallo – successfully applied to the Beamer 2. This results in even less forward speed and provides what most pilots need – the advantages of a round canopy’s vertical flightpath, plus those of a steerable forwards-flying Rogallo. For example, if the Beamer opens alongside a rock face, or in strong wind, its initial descent will be almost vertical. Then, after its steering lines have been activated, the Rogallo’s forward speed can be used. If the pilot has enough height he can then steer the Beamer 3 away from danger (e.g. rocks, water, buildings etc.).
Steering and flying forwards – the Beamer’s speciality!
Paraglider under tow: In real-life reserve-throwing situations the paraglider can become a massive problem. In many cases the paraglider is already collapsed, both during and after reserve opening, and therefore prevented from flying. Here the Beamer 3 descent is a pure pleasure. The canopy reacts immediately to steering commands and sinks at its slowest rate. When the reserve is thrown while the paraglider is flying normally, such as during SIV training, the descent characteristics of both Rogallo and round reserve can be affected. If the paraglider reopens itself during a reserve descent it can easily be prevented from flying by B-stall, or reefing in. This will greatly improve steerability. Countless examples in practice confirm the problem-free behaviour of all Beamers in every possible situation.
Technical data
light 100 | light 130 | light 170 | ||
---|---|---|---|---|
Area (flat): | m2 | 35.47 | 41.75 | 58 |
Weight: | g | 1180 | 1370 | 2200 |
Weight incl. inner container: | g | 1230 | 1420 | 2240 |
Weight of bridle extension for front container mounting: | g | 20 | 20 | 20 |
Max. load: | kg | 90 (100)* | 130 | 170 |
Sink rate loaded at max load (EN Test): | m/s | 3.7 | 3.8 | 3.6 |
Opening time (EN Test): | s | 2 | 2 | 2 |
Volume: | ccm | 3324 | 3837 | 6058 |
No. of gore: | - | 16 | 18 | 18 |
No. of middle lines: | - | 8x2 | 9×2 | 10x2 |
Certification type: | - | EP/RG 104.2013 | EP 080.2013/RG 080.2013 | EP 281.2019 |
Applicable testing guidelines/standards: | - | EN 12491:2001 / 2.DV; LuftGerPV §1, Nr.7c | EN 12491:2001 / 2.DV; LuftGerPV §1, Nr.7c | EN 12491:2001 / 2.DV; LuftGerPV §1, Nr.7c |
